Kit 2 Brake Discs ABAKUS 231-03-037 | Mercedes Vito (W638) from 1996 to 2003 | OE A6384210112 | 6384210112

€60.50

VAT included

About the Products

After-sales service

Do you need help ?

Line 1: 868 165 112
Line 2: 968 306 733
WhatsApp: 619 800 155

Remember to check reference OEM with your original autopart

Brake Fluid | WINX Clutch Fluid 500 ml DOT 4 | FMVSS 116 DOT 3 | FMVSS 116 DOT 4 | SAE J1703 | ISO 4925 3 | ISO 4925 4

€5.49

VALEO Brake Fluid DOT 5.1 500 ml | FMVSS 116 DOT 3/4/5.1 | SAE J1703 | SAE J1704 | ISO 4925 3/4/5.1

€10.89

Brake Pads Mercedes Sprinter | Vito | Front Axle | Not Prepared for Wear Indicator | BOSCH | OE 0004214110

€29.04

Brake Pads SRLine Mercedes Vito (W638) | Rear Axle | Wear Indicator Ready | OEM A003 420 0220

€16.94

Brake Fluid | WINX Clutch Fluid 500 ml DOT 4 | FMVSS 116 DOT 3 | FMVSS 116 DOT 4 | SAE J1703 | ISO 4925 3 | ISO 4925 4

€5.49

VALEO Brake Fluid DOT 5.1 500 ml | FMVSS 116 DOT 3/4/5.1 | SAE J1703 | SAE J1704 | ISO 4925 3/4/5.1

€10.89

Brake Pads Mercedes Sprinter | Vito | Front Axle | Not Prepared for Wear Indicator | BOSCH | OE 0004214110

€29.04

Brake Pads SRLine Mercedes Vito (W638) | Rear Axle | Wear Indicator Ready | OEM A003 420 0220

€16.94

Brake Fluid | WINX Clutch Fluid 500 ml DOT 4 | FMVSS 116 DOT 3 | FMVSS 116 DOT 4 | SAE J1703 | ISO 4925 3 | ISO 4925 4

€5.49

VALEO Brake Fluid DOT 5.1 500 ml | FMVSS 116 DOT 3/4/5.1 | SAE J1703 | SAE J1704 | ISO 4925 3/4/5.1

€10.89

Brake Pads Mercedes Sprinter | Vito | Front Axle | Not Prepared for Wear Indicator | BOSCH | OE 0004214110

€29.04

Brake Pads SRLine Mercedes Vito (W638) | Rear Axle | Wear Indicator Ready | OEM A003 420 0220

€16.94

Product Description:

Kit 2 Brake Discs ABAKUS 231-03-037 | Mercedes Vito (W638) from 1996 to 2003 | OE A6384210112 | 6384210112

Brake Disc Type: Ventilated

Height [mm]: 40

Height [mm]: 60

Centring Diameter [mm]: 67

Brake Disc Thickness [mm]: 22

Outside Diameter [mm]: 276

Number of holes: 5

Part No.:

S71-0163A

Similar OEM part number:

16887 | 24012201621 | 24032201621 | 562054B | ADU174369 | E190R-02C0074/0066 | 0986479B53 | BD761 | 9698310 | 562054CH | 800-416 | BG3296 | B130035 | 10642 | DDF860C-1 | DDF860 | DDF860C | DDF860-1 | BS7045 | BS4670B | BS4670 | DF29416 | 78BD6380-2 | 562054J | 562054JC | 1031720 | 6041400 | 353612834240 | 431602040990 | 360406032200 | 15788 | 15788C | A6384210112 | 6384210112 | 800-416 | 23-0416 | 6110407 | 155212034 | MDC1038 | 203335 | 313335 | 6384210112 | 52148 | 52148PRO | V286 | V288 | BDC4670 | BDC4679 | BSF4670 | BDC4670HC | 6460,1 | RT2583-GLT5 | RT2583 | RT2583-GLT9 | RT2583-GLT3 | RT2583-GLT6 | RT2583-GL | 10910642 | 92074400 | 92074403 | 982000744 | 98200074401PRO | 98200074401 | 400857 | DF2797 | V30-80023 | 186551 | 400144800 | 400.1448.20 |

Mounting Side:

Front Axle

Compatible Models:

Modelo \| Año Compatible	CC \| CV \| KW	Clave de Motor
MERCEDES\|	\|\|
V-CLASS (638/2), 02.96-07.03\|	\|\|
V 200 CDI (638.294)\|03.99-07.03	2148\|102\|75	OM 611.980
V 230 (638.234, 638.294)\|10.96-07.03	2295\|143\|105	M 111.978 \| M 111.980
V 220 CDI (638.294)\|03.99-07.03	2148\|122\|90	OM 611.980
V 280 (638.244, 638.294)\|08.97-07.03	2792\|174\|128	M 104.900
V 230 TD (638.274)\|09.96-07.03	2299\|98\|72	OM 601.970
V 200 (638.214, 638.294)\|02.97-07.03	1998\|129\|95	M 111.948 \| M 111.950
VITO Box (W638), 03.97-07.03\|	\|\|
108 CDI 2.2 (638.094)\|03.99-07.03	2148\|82\|60	OM 611.980
112 CDI 2.2 (638.094)\|03.99-07.03	2148\|122\|90	OM 611.980
114 2.3 (638.034, 638.094)\|03.97-07.03	2295\|143\|105	M 111.978 \| M 111.980
110 CDI 2.2 (638.094)\|03.99-07.03	2148\|102\|75	OM 611.980
110 D 2.3 (638.074, 638.078)\|03.97-07.03	2299\|98\|72	OM 601.970
113 2.0 (638.014, 638.094)\|03.97-07.03	1998\|129\|95	M 111.948 \| M 111.950
108 D 2.3 (638.064, 638.068)\|03.97-07.03	2299\|79\|58	OM 601.942
VITO Bus (W638), 02.96-07.03\|	\|\|
110 CDI 2.2 (638.194)\|03.99-07.03	2148\|102\|75	OM 611.980
108 D 2.3 (638.164)\|02.96-07.03	2299\|79\|58	OM 601.942
112 CDI 2.2 (638.194)\|03.99-07.03	2148\|122\|90	OM 611.980
108 CDI 2.2 (638.194)\|03.99-07.03	2148\|82\|60	OM 611.980
114 2.3 (638.134, 638.194)\|12.96-07.03	2295\|143\|105	M 111.978 \| M 111.980
113 2.0 (638.114, 638.194)\|02.96-07.03	1998\|129\|95	M 111.948 \| M 111.950
110 TD 2.3 (638.174)\|02.96-07.03	2299\|98\|72	OM 601.970

Other Specifications:

Manufacturer: ABAKUS

Height [mm]: 60

Centering Diameter [mm]: 67

Brake Disc Thickness [mm]: 22

Outside Diameter [mm]: 276

Bore Crown [mm]: 112

Up to Hole Diameter [mm]: 15.1

Minimum Thickness [mm]: 19

Number of Holes: 5

Brake Disc Type: Ventilated

Without Wheel Bearing

Without ABS Ring

Homologation: ECE R90

Replace in Pairs Only | Requires Specialist Fitting and Removal

Warranty:

1 Year Warranty Against Manufacturing Defect.

The images of our products may vary according to the manufacturer, maintaining all the technical characteristics and compatibilities indicated in the product specifications.

Replacement parts category: Sistema de Frenado
Kind of replacement part: Disco de Freno
Mounting Side: Front

Modelo \| Año Compatible	CC \| CV \| KW	Clave de Motor
MERCEDES\|	\|\|
V-CLASS (638/2), 02.96-07.03\|	\|\|
V 200 CDI (638.294)\|03.99-07.03	2148\|102\|75	OM 611.980
V 230 (638.234, 638.294)\|10.96-07.03	2295\|143\|105	M 111.978 \| M 111.980
V 220 CDI (638.294)\|03.99-07.03	2148\|122\|90	OM 611.980
V 280 (638.244, 638.294)\|08.97-07.03	2792\|174\|128	M 104.900
V 230 TD (638.274)\|09.96-07.03	2299\|98\|72	OM 601.970
V 200 (638.214, 638.294)\|02.97-07.03	1998\|129\|95	M 111.948 \| M 111.950
VITO Box (W638), 03.97-07.03\|	\|\|
108 CDI 2.2 (638.094)\|03.99-07.03	2148\|82\|60	OM 611.980
112 CDI 2.2 (638.094)\|03.99-07.03	2148\|122\|90	OM 611.980
114 2.3 (638.034, 638.094)\|03.97-07.03	2295\|143\|105	M 111.978 \| M 111.980
110 CDI 2.2 (638.094)\|03.99-07.03	2148\|102\|75	OM 611.980
110 D 2.3 (638.074, 638.078)\|03.97-07.03	2299\|98\|72	OM 601.970
113 2.0 (638.014, 638.094)\|03.97-07.03	1998\|129\|95	M 111.948 \| M 111.950
108 D 2.3 (638.064, 638.068)\|03.97-07.03	2299\|79\|58	OM 601.942
VITO Bus (W638), 02.96-07.03\|	\|\|
110 CDI 2.2 (638.194)\|03.99-07.03	2148\|102\|75	OM 611.980
108 D 2.3 (638.164)\|02.96-07.03	2299\|79\|58	OM 601.942
112 CDI 2.2 (638.194)\|03.99-07.03	2148\|122\|90	OM 611.980
108 CDI 2.2 (638.194)\|03.99-07.03	2148\|82\|60	OM 611.980
114 2.3 (638.134, 638.194)\|12.96-07.03	2295\|143\|105	M 111.978 \| M 111.980
113 2.0 (638.114, 638.194)\|02.96-07.03	1998\|129\|95	M 111.948 \| M 111.950
110 TD 2.3 (638.174)\|02.96-07.03	2299\|98\|72	OM 601.970
