Opel Corsa Combo C (X01) Meriva A (X03) Tigra (X04) Outer CV Joint | Driveshaft | OE 771028930
search
  • Opel Corsa Combo C (X01) Meriva A (X03) Tigra (X04) Outer CV Joint | Driveshaft | OE 771028930
  • Opel Corsa Combo C (X01) Meriva A (X03) Tigra (X04) Outer CV Joint | Driveshaft | OE 771028930
  • Opel Corsa Combo C (X01) Meriva A (X03) Tigra (X04) Outer CV Joint | Driveshaft | OE 771028930
  • Opel Corsa Combo C (X01) Meriva A (X03) Tigra (X04) Outer CV Joint | Driveshaft | OE 771028930

Opel Corsa Combo C (X01) Meriva A (X03) Tigra (X04) Outer CV Joint | Driveshaft | OE 771028930

€26.62
VAT included
Reference: 63190850A



It is advisable to check the OEM part number on most replacement parts.



Delivery Policy



After-Sales Service



About the Products

Product Description:

Outer CV Joint Opel Corsa Combo C (X01) Meriva A (X03) Tigra (X04) | Propshaft Joint | OE 771028930 | 1243300210

Wheel-side Outer Teeth: 22 | Wheel-side Inner Teeth: 23 | Thread Size: M20x1 | Length: 158mm | O-ring Diameter: 52mm | ABS Ring Teeth: 29

Reference:

63190850A

Similar OEM Reference:

CV9503A | BCJ1178 | BSG65-340-016 | 607-451 | ECV112 | C120041 | 77-OP-1041A | 20398018/S | OP1074 | 3620K | GCO44002 | 1243300210 | 6029 | 304391 | 15-1451 | 12-231343 | 513639 | 374403 | 9201725 | CW-2612 | 75322S | 771028930 | VKJA41115A | VKJA3111 | OJK53.021 | 23992 | 40-0312 | 141-04-034 |

Mounting Side:

Front Axle | Outer Side | Wheel Side

Compatible Models:

OPEL

COMBO C (X01) de | 2000 | 2001 | 2002 | 2003 |

COMBO C (X01) de | 2003 | 2004 | 2005 | 2006 | 2007 | 2008 | 2009 | 2010 |

CORSA C (X01) de | 2000 | 2001 | 2002 | 2003 |

CORSA C (X01) de | 2003 | 2004 | 2005 | 2006 |

CORSA C (X01) de | 2003 | 2004 | 2005 | 2006 |

MERIVA A (X03) de | 2006 | 2007 | 2008 | 2009 | 2010 |

TIGRA (X04) de | 2004 | 2005 | 2006 | 2007 | 2008 | 2009 |

Modelo | Año Compatible CC | CV | KW Clave de Motor
OPEL| ||
COMBO Tour, 10.01-12.11| ||
1.3 CDTI 16V|10.05-12.11 1248|75|55 Z 13 DTJ
1.7 DTI 16V|10.01-06.04 1686|75|55 Y 17 DT
1.3 CDTI 16V|06.04-01.11 1248|69|51 Y 13 DT | Z 13 DT
COMBO Van (Furgoneta) /minivan, 10.01-| ||
1.3 CDTI 16V|10.05-12.12 1248|75|55 Z 13 DTJ
1.3 CDTI 16V|08.05-_____ 1248|69|51 Z 13 DT
1.7 DTI 16V|10.01-_____ 1686|75|55 Y 17 DT
CORSA C (X01), 09.00-12.09| ||
1.4 (F08, F68)|09.00-12.09 1389|90|66 Z 14 XE
1.3 CDTI (F08, F68)|06.03-12.09 1248|70|51 Y 13 DT | Z 13 DT
1.8 (F08, F68)|09.00-12.09 1796|125|92 Z 18 XE
1.7 DI (F08, F68)|09.00-12.09 1686|65|48 Y 17 DTL
1.7 DTI (F08, F68)|09.00-12.09 1686|75|55 Y 17 DT
MERIVA A MPV - multi-purpose vehicle (X03), 05.03-05.10| ||
1.3 CDTI (E75)|04.05-05.10 1248|69|51 Y 13 DT | Z 13 DT
1.3 CDTI (E75)|09.03-05.10 1248|75|55 Z 13 DTJ
1.7 DTI (E75)|09.03-05.10 1686|75|55 Y 17 DT
1.8 (E75)|05.03-05.10 1796|125|92 Z 18 XE
TIGRA TwinTop (X04), 06.04-12.10| ||
1.8 (R97)|06.04-12.10 1796|125|92 Z 18 XE

Other Specifications:

External Teeth on Wheel Side: 22

Internal Teeth on Wheel Side: 23

Thread Size: M20x1

Length: 158mm

O-Ring Diameter: 52mm

Number of ABS Ring Teeth: 29

Grease Lubrication

Mounting hardware included

Belts included

Requires assembly/disassembly by specialized personnel!

Warranty:

1-Year Warranty Against Manufacturing Defects.

Images of our products may vary depending on the manufacturer, but all technical characteristics and compatibility indicated in the product specifications are maintained.

63190850A

Data sheet

Replacement parts category
Mechanics
Kind of replacement part
CV Joint
