Clutch Conversion Kit Flywheel Clutch from Dual Mass Flywheel to Rigid Engine | PSA Group 1.6 HDi Engine 9H DV6 | 0532Q4
  • Clutch Conversion Kit Flywheel Clutch from Dual Mass Flywheel to Rigid Engine | PSA Group 1.6 HDi Engine 9H DV6 | 0532Q4
  • Clutch Conversion Kit Flywheel Clutch from Dual Mass Flywheel to Rigid Engine | PSA Group 1.6 HDi Engine 9H DV6 | 0532Q4

Clutch Conversion Kit Flywheel Clutch from Dual Mass Flywheel to Rigid Engine | PSA Group 1.6 HDi Engine 9H DV6 | 0532Q4

€254.10
VAT included
Reference:
15556821

Quantity
Available

Do you need help ?

Line 1: 868 165 112
Line 2: 968 306 733
WhatsApp: 619 800 155

Remember to check reference OEM with your original autopart

You might also like

Product Description:

SRLine Clutch Conversion Kit with Rigid Flywheel | PSA Group 1.6 HDi Engine Type 9H DV6TED4 DV6ATED4 | Clutch Disc | Pressure Plate | Thrust Bearing | Flywheel | Screw Fittings | OE 0532R7 | 0532X9 | 0532P5 | 0532Q3 | 0532Q4 | 0532P7 | 0532W9

With Rigid Motor Flywheel | With Thrust Bearing | With Clutch Disc | With Mounting Screw Set | With Mounting Screw Kit

Clutch Type: Dual Mass Flywheel to Rigid Flywheel Conversion

Hub Profile : Hub (mm): 20,7 x 18,2

No. of Teeth: 18

Part no:

15556821

Similar OEM part number:

0532R7 | 0532X9 | 0532P5 | 0532Q3 | 0532Q4 | 0532P7 | 0532W9 | 0532 R7 | 0532 X9 | 0532 P5 | 0532 Q3 | 0532 Q4 | 0532 P7 | 0532 W9 | 0532.R7 | 0532.X9 | 0532.P5 | 0532.Q3 | 0532. Q4 | 0532.P7 | 0532.W9 | LKCA620046F | 415039610 | 600008400 |600 0084 00 | 415 0396 10 | 010228820 | 2290601002 | 2294001594 | 2290 601 002 | 2294 001 594 | 828392 | 835071 | 835207

Mounting Side:

_

Compatible Models:

CITROEN

BERLINGO (7_) de | 2008 | 2009 | 2010 | 2011 | 2012 |

BERLINGO (7_) de | 2012 | 2013 | 2014 | 2015 |

BERLINGO (7_) de | 2015 | 2016 | 2017 | 2018 |

C2 (JM) de | 2003 | 2004 | 2005 | 2006 | 2007 | 2008 |

C2 (JM) de | 2008 | 2009 |

C3 (FC) de | 2002 | 2003 | 2004 | 2005 |

C3 (FC) de | 2005 | 2006 | 2007 | 2008 | 2009 | 2010 |

C3 PICASSO (SH) de | 2008 | 2009 | 2010 | 2011 | 2012 | 2013 | 2014 | 2015 | 2016 | 2017 | 2018 | 2019 | 2020 | 2021 |

C4 (LA|LC) de | 2004 | 2005 | 2006 | 2007 | 2008 |

C4 (LA|LC) de | 2008 | 2009 | 2010 |

C4 PICASSO (UA|UD) de | 2006 | 2007 | 2008 | 2009 | 2010 |

C4 PICASSO (UA|UD) de | 2010 | 2011 | 2012 | 2013 |

C5 (RC|RE) de | 2004 | 2005 | 2006 | 2007 | 2008 |

C5 (RD|TD) de | 2008 | 2009 | 2010 | 2011 | 2012 | 2013 | 2014 | 2015 | 2016 | 2017 |

XSARA PICASSO (N68) de | 1999 | 2000 | 2001 | 2002 | 2003 | 2004 | 2005 | 2006 | 2007 | 2008 | 2009 | 2010 |

PEUGEOT

1007 (K) de | 2005 | 2006 | 2007 | 2008 | 2009 |

206 (2) de | 1998 | 1999 | 2000 | 2001 | 2002 | 2003 |

206 (2) de | 2003 | 2004 | 2005 | 2006 | 2007 | 2008 | 2009 |

207 | 207 Plus (W) de | 2006 | 2007 | 2008 | 2009 | 2010 | 2011 | 2012 | 2013 |

207 | 207 Plus (W) de | 2006 | 2007 | 2008 | 2009 | 2010 | 2011 | 2012 | 2013 |

307 (3) | SW | CC | Break de | 2001 | 2002 | 2003 | 2004 | 2005 |

307 (3) | SW | CC | Break de | 2005 | 2006 | 2007 | 2008 | 2009 |

308 (4) de | 2007 | 2008 | 2009 | 2010 | 2011 |

308 (4) de | 2011 | 2012 | 2013 |

407 (6) de | 2004 | 2005 | 2006 | 2007 | 2008 |

407 (6) de | 2008 | 2009 | 2010 | 2011 |

508 (8E) de | 2010 | 2011 | 2012 | 2013 | 2014 |

508 (8E) de | 2015 | 2016 | 2017 | 2018 |

PARTNER (B9) de | 2008 | 2009 | 2010 | 2011 | 2012 |

PARTNER (B9) de | 2012 | 2013 | 2014 | 2015 |

PARTNER (B9) de | 2015 | 2016 | 2017 | 2018 |

Modelo | Año Compatible CC | CV | KW Clave de Motor
PEUGEOT| ||
1007 (KM_), 04.05-| ||
1.6 HDi|06.07-_____ 1560|109|80 9HZ (DV6TED4)
206 CC (2D), 09.00-12.08| ||
1.6 HDi 110|04.05-02.07 1560|109|80 9HZ (DV6TED4)
206 liftback (2A/C), 08.98-12.12| ||
1.6 HDi 110|05.04-02.07 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
206 SW (2E/K), 07.02-| ||
1.6 HDi 110|05.04-_____ 1560|109|80 9HZ (DV6TED4)
207 (WA_, WC_), 02.06-12.15| ||
1.6 HDi|02.06-10.13 1560|90|66 9HV (DV6TED4) | 9HV (DV6TED4B) | 9HV (DV6TED4BU) | 9HX (DV6ATED4)
1.6 HDi|02.06-10.13 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
207 CC (WD_), 02.07-01.15| ||
1.6 HDi|02.07-01.15 1560|109|80 9HZ (DV6TED4)
207 SW (WK_), 02.07-12.13| ||
1.6 HDi|06.07-12.12 1560|109|80 9HZ (DV6TED4)
307 (3A/C), 08.00-12.12| ||
1.6 HDi|04.05-03.09 1560|90|66 9HV (DV6TED4B) | 9HV (DV6TED4BU) | 9HX (DV6ATED4)
1.6 HDi 110|02.04-03.09 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
307 Break (3E), 03.02-12.09| ||
1.6 HDi 110|02.04-04.08 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
307 SW (3H), 03.02-12.09| ||
1.6 HDi 110|11.03-12.07 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
308 I (4A_, 4C_), 09.07-12.16| ||
1.6 HDi|09.07-10.14 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
1.6 HDi|09.07-10.14 1560|90|66 9HV (DV6TED4B) | 9HV (DV6TED4BU) | 9HX (DV6ATED4)
308 SW I (4E_, 4H_), 09.07-10.14| ||
1.6 HDi|09.07-10.14 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
1.6 HDi|09.07-10.14 1560|90|66 9HV (DV6TED4BU) | 9HX (DV6ATED4)
407 (6D_), 02.04-12.11| ||
1.6 HDi 110 (6D9HZC, 6D9HYC)|05.04-12.10 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
407 SW (6E_), 05.04-12.11| ||
1.6 HDi 110|05.04-12.10 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
508 I (8D_), 11.10-12.18| ||
1.6 HDi|02.12-12.18 1560|115|84 9HD (DV6CTED)
1.6 HDi|11.10-12.18 1560|112|82 9HL (DV6C) | 9HR (DV6C)
508 SW I (8E_), 11.10-12.18| ||
1.6 HDi|11.10-12.18 1560|112|82 9HL (DV6C) | 9HR (DV6C)
1.6 HDi|02.12-12.18 1560|115|84 9HL (DV6C) | 9HR (DV6C)
PARTNER Tepee, 04.08-| ||
1.6 HDi|04.08-_____ 1560|109|80 9HZ (DV6TED4)
1.6 HDi 16V|04.08-_____ 1560|90|66 9HV (DV6TED4B) | 9HV (DV6TED4BU)
PARTNER Van (Furgoneta) /minivan, 04.08-| ||
1.6 HDi 16V|04.08-_____ 1560|90|66 9HS (DV6TED4BU) | 9HX (DV6AUTED4)
1.6 HDi|04.08-_____ 1560|109|80 9HZ (DV6TED4)
CITROËN| ||
BERLINGO MULTISPACE (B9), 04.08-| ||
1.6 HDi 90|04.08-_____ 1560|90|66 9HV (DV6TED4B) | 9HX (DV6ATED4)
1.6 HDi 110|04.08-_____ 1560|109|80 9HZ (DV6TED4)
BERLINGO Van (Furgoneta) /minivan (B9), 04.08-| ||
1.6 HDi 90 16V|04.08-_____ 1560|90|66 9HS (DV6TED4BU) | 9HX (DV6AUTED4)
1.6 HDi 110|04.08-_____ 1560|109|80 9HZ (DV6TED4)
C2 (JM_), 07.03-09.17| ||
1.6 HDi|09.05-12.09 1560|109|80 9HZ (DV6TED4)
C3 I (FC_, FN_), 02.02-| ||
1.6 16V HDi|09.05-_____ 1560|109|80 9HZ (DV6TED4)
C3 Picasso (SH_), 02.09-| ||
1.6 HDi|02.09-_____ 1560|109|80 9HZ (DV6TED4)
C4 Coupe (LA_), 11.04-12.13| ||
1.6 HDi|11.04-07.11 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
1.6 HDi|11.04-07.11 1560|90|66 9HV (DV6TED4B) | 9HV (DV6TED4BU) | 9HX (DV6ATED4)
C4 Grand Picasso I (UA_), 10.06-12.13| ||
1.6 HDi|10.06-06.11 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
C4 I (LC_), 11.04-12.14| ||
1.6 HDi|11.04-07.11 1560|90|66 9HV (DV6TED4B) | 9HV (DV6TED4BU) | 9HX (DV6ATED4)
1.6 HDi|11.04-07.11 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
C4 I sedan, 07.06-| ||
1.6 HDi|07.06-07.11 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
C4 PICASSO I (MPV) (UD_), 10.06-12.15| ||
1.6 HDi|02.07-08.13 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
C5 II (RC_), 08.04-09.08| ||
1.6 HDi (RC8HZB)|09.04-01.08 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
C5 II Break (RE_), 09.04-| ||
1.6 HDi (RE9HZC, RE9HYB)|09.04-01.08 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)
C5 III (RD_), 02.08-| ||
1.6 HDi 110|02.08-_____ 1560|109|80 9HZ (DV6TED4)
1.6 HDi 110|07.10-_____ 1560|112|82 9HL (DV6C) | 9HR (DV6C)
1.6 HDi 115|01.12-_____ 1560|114|84 9HL (DV6C) | 9HR (DV6C)
C5 III Break (RW_), 02.08-| ||
1.6 HDi 110|07.10-_____ 1560|112|82 9HL (DV6C) | 9HR (DV6C)
1.6 HDi 115|01.12-_____ 1560|114|84 9HL (DV6C) | 9HR (DV6C)
1.6 HDi 110|02.08-_____ 1560|109|80 9HZ (DV6TED4)
XSARA PICASSO (N68), 09.99-06.12| ||
1.6 HDi|05.04-12.11 1560|109|80 9HY (DV6TED4) | 9HZ (DV6TED4)

Other Specifications:

Clutch Pressure Plate | Replaces Pressure Plate with OE Ordering Number 2004CA | 2004CS | 2004EE

Clutch Disc | Replaces Disc with OE Part No. 9674343180 | 9685019880 | 9800709680 | 9805958080 | 9817730580

Thrust or Clutch Release Bearing - OE-No. 1611266780, 2041A7, 204163, 204194, 9633922480, 9688226180

Motor Flywheel - Replaces Two Mass Motor Flywheel OE part number 0532W9, 0532X9, 9673234480, 9674342980

For exact identification please observe photo, article content, original part numbers and vehicle application table as well as mounting procedure.

With Rigid Motor Flywheel , With Thrust Bearing , With Clutch Disc , With Mounting Screw Set

Clutch Type: Conversion from Dual Mass Flywheel to Rigid Flywheel

Hub Profile : Hub (mm): 20,7 x 18,2

No. of Teeth: 18

Outside Diameter (mm): 228

Ejection force (Newton): 5750

Tightening torque (Newton): 60

Warranty:

1 Year Warranty Against Manufacturing Defect.


The images of our products may vary according to the manufacturer, maintaining all the technical characteristics and compatibilities indicated in the product specifications. Our company is associated to Fremm (Regional Federation of Metal Entrepreneurs of Murcia) and is part of the Association of Automobile Spare Parts Dealers of the Region of Murcia (ACRAREM).

Replacement parts category
Mechanics
Kind of replacement part
Clutch
Marca
CITROEN
Marca
PEUGEOT
Modelo
508 2011 -2018
Modelo
C5 2008 - 2017
Modelo
1007 2007 -2010
Modelo
C4 PICASSO 10/2006 - 06/2010
Modelo
407 2004 - 2009
Modelo
BERLINGO 2008 - 2012
Modelo
206 1998 - 2009
Modelo
C2 2003 - 2007
Modelo
C5 2004 - 2007
Modelo
308 2007 - 2011
Modelo
C3 2009 - 2012
Modelo
307 y 307 CC 2005 - 2010
Modelo
C3 PICASSO 2009 - 2017
Modelo
C4 2004 - 2008
Modelo
PARTNER 2008 - 2012
Modelo
207 2006 - 2009
